AirStation™ Nfiniti™ High Power Gigabit Broadband ADSL2+ Modem Router



- Wireless connections up to 300Mbps*
- Optimised hardware and software extends wireless performance and range
- Energy save feature reduce consumption up to 65%
- High Speed ADSL2+ Connection with Line Rates of up to 24Mbps
Downstream and 3Mbps Upstream - Easy setup with AirStation One-Touch Secure System (AOSS™)
- USB port for NAS and Printer capabilities
- Built-In media server streams multimedia content to DLNA clients on your network
- Movie engine feature to optimise streaming media
- BitTorrent Client for downloading rich media files
- Store, share and access files from any web browser with WebAccess
- VPN feature allows you to access the network remotely

About AOSS™


Name WBMR-HP-G300H

Wireless Interface

Standard Compliance IEEE802.11n/g/b
Security WPA2-PSK (AES,TKIP), WPA-PSK (AES, TKIP), WEP (128/64bit)
Transfer Rates Max. 300Mbps(IEEE802.11n) Max. 54Mbps(IEEE802.11g) Max. 11Mbps(IEEE802.11b)
Antenna External anntena, 2x2

Wired Interface

Standard Compliance IEEE802.3/3u/3ab
Speed and Flow Controll 10/100/1000 Mbps (Auto Sensing)
Number of Ports LAN : 4 x RJ-45 (Auto MDIX)

USB Interface

Standard Compliance USB 2.0

ADSL Interface

Standard Compliance TR067/068, T1.413-2, G.992.1 (G.dmt), G.992.3 (G.dmt.bis), G.992.5 (G.dmt.plus), ADSL, ADSL2, ADSL2+
Number of DSL Ports 1 x RJ-11

USB Interface

Connector Type A type
Number of Ports 1
Feature NAS,Print Server

Key Feature

Feature -


OS Support Windows® 7 (32/64-bit), Vista® (32/64-bit), XP Mac OS® X 10.7, 10.6, 10.5, 10.4
Power Consumption 12.0W (Max)
Dimensions (LxWxH, mm) (HxWxL, mm)165 x 158 x 35 mm
Weight 380 g
Operating Environment 0-40°C, 20-80% (non-condensing)
Power Supply AC 100-240V, 50/60Hz
Warranty 2-year / 3-year # Products covered by the three-year warranty include those purchased on or after April 1, 2011 (please present receipt to verify date of purchase) or manufactured after April 1, 2011 (instructions for checking the month of manufacture are provided here).

Package Contents

WBMR-HP-G300H / 2013-07-05Product DatasheetDownload
